PFC-25T Pneumatic Desktop Ferrule Terminal Crimper

Market Price: 210

Wholesale Price:$ 160.00

Pneumatic cold pressing terminal crimper, also known as pneumatic terminal crimper or pneumatic terminal crimping tool, is a kind of tool to provide power (without plug-in) by connecting the input air energy of air compressor, which solves the problems of manual crimping tools such as tedious, laborious and low efficiency ;
Pneumatic terminal crimping tools are mainly used to crimp cold pressed terminals, such as insulated terminals, bare terminals, ferrule terminals, plug spring terminals, flag terminals, nipple crimping caps, etc., which have the characteristics of high crimping efficiency, labor-saving operation, safety and convenience ;
According to the different types of pressing connection, pneumatic terminal crimping machine can be divided into special-purpose type and multi-functional type; according to the different operation modes, it can be divided into handheld type and desktop type ;
PFC-25T is specially used for crimping ferrule terminals. Its crimping range is 0.14-2.5mm², and the shape is trapezoidal after crimping. It can be fixed on the desktop through accessories. If there are other requirements for the shape after crimping, please select quadrangle or hexagon ;
Desktop pneumatic crimping tool PFC-25T can be inserted into tubular terminals for crimping at the left, right and front of the crimping joint through scientific and reasonable design, which greatly improves the practicability and is widely used in assembly workshops and wire harness processing in the electrical industry ;
Fixed clamp PFC-25T has the same function as Phoenix ZAP-25T, but with its high cost performance, stable and reliable quality and efficient after-sales service, it is supported and recognized by the majority of customers ;
PFC-25T is suitable for 0.4-0.6MPA air pressure. If it exceeds the value, it will reduce the service life of the tool, damage the internal parts and other consequences. It is recommended to install a pressure regulating valve to adjust the air pressure ;
PFC pneumatic clamp series can be divided into hand-held type and desktop type, which can be selected according to the application environment ;

点击购买

Instructions for use
Connect the tool to the air compressor, put the terminal of the wire into any pressing interface of the tool, press the operating handle to complete the crimping, release the handle and take out the terminal

Product description
Name: desktop pneumatic crimper
Model: PFC-25T
Applicable object: ferrule terminals
Applicable pressure: 0.4-0.6MPA
Crimping range: 0.14-0.25mm²
Product size: Ø 140 * 200 * 70mm
Weight: 1.2kg
Accessories included with the product: foot switch, clamp, adapter, instruction manual

Product characteristics
It can be fixed, light weight and low operation requirements
The unique groove design is more humanized
Standard shape after pressing

Common problems of pneumatic crimping machine
1. The air pressure does not meet the standard. If the air pressure is too high or too low, the use effect of the crimping machine will be affected, and the operation shall be carried out in strict accordance with the instructions of the corresponding tools; < br / > if the air pressure is too high or too low, the use effect of the crimping machine will be affected ;
2. Shape deformation after pressing. The wire does not match the terminal, the terminal tube is empty after inserting the wire, and it is extruded or cannot be pressed after crimping, the wire is inserted into the terminal tube
3. The crimping efficiency is not as expected. Pneumatic crimper is a semi-automatic tool, its efficiency is affected by many convenient factors, such as crimping terminal type, terminal size, unskilled and so on ;
